33.528m HD200 Modular Bailey Bridge Successfully Delivered in Philippines With External 2.6m Pipe Support Beam

Recently, our overseas engineering project achieved an important milestone. The 33.528m HD200-type Bailey Bridge project in the Philippines has been fully completed and handed over to the client. The whole on-site erection was finished within only 10 days. Our efficient execution and customized engineering solution have won full recognition from the customer.

The bridge has a clear span of 33.528 meters, adopting HD200 modular steel truss system. Structural calculation and optimization are carried out strictly in accordance with AASHTO American bridge design specifications. To satisfy the client's special operation requirements, an external 2.6m pipe support beam is installed on the outer side of the main bridge. The integrated design realizes vehicle transportation and pipeline laying simultaneously. It becomes a representative case of customized application of modular bailey bridges.

The Philippines features tropical marine climate with high temperature, heavy rainfall and frequent typhoons. Steel structures suffer continuous erosion from humidity and salt spray. During design phase, our technical team fully considered local climatic conditions and upgraded anti-corrosion solutions. All primary structural components adopt hot-dip galvanizing treatment to resist corrosion in humid tropical areas and guarantee long-term safe operation.

During construction, our professional structural engineers were dispatched to the site to provide full-range technical guidance. We supported local construction crews in truss assembly, pipe bracket installation, alignment adjustment and load verification. Potential risks during outdoor construction in tropical regions were well controlled. The whole bridge assembly was accomplished within 10 days, which fully demonstrates the core strengths of HD200 bailey bridge: modular design and ultra-fast erection.

After commissioning, this bridge will remove regional traffic barriers and support pipeline transportation, greatly improving the efficiency of local engineering operations. The successful delivery marks the solid landing of our multi-functional customized steel bridge solution in the Philippine market. Different from ordinary traffic-only bailey bridges, this project proves outstanding expandability of the HD200 system. It can deliver integrated solutions combining vehicle passage and pipeline layout for industrial zones, mining projects and water conservancy infrastructure across the Philippines.

The Philippine government keeps increasing investment in transportation and energy infrastructure. Typhoons and seasonal floods create continuous demand for emergency steel crossings and temporary bridges. Based on this successful cooperation, our company will further explore the Philippines and wider Southeast Asian market. We will supply HD200, TSR3 and other series modular steel bridges complying with AASHTO standards, offering one-stop services including technical design, component manufacturing and on-site engineering supervision. We aim to cooperate with local partners to promote regional infrastructure development.
